Product Highlights

Powerful 1100W J-Curve Array Sound — The STAGEPAS 1K mkII is driven by a high-efficiency 1100W Class-D amplifier, delivering an impressive 125 dB SPL.
Professional 5-Channel Digital Mixer with App Control — Versatile connectivity with three mono mic/line inputs (two with Hi-Z) and a stereo input.
Simple Setup and Superior Portability — The system's lightweight components, including the subwoofer, spacers, and array speaker, assemble quickly without the need for speaker stands or cables.
Bluetooth 5.0 for audio streaming and remote control
Remote control via STAGEPAS Controller app for iOS/Android

Available Since: August, 2026
Item No.: 20502074
Local SKU: OS

Powerful 1100W J-Curve Array Sound

The STAGEPAS 1K mkII is driven by a high-efficiency 1100W Class-D amplifier, delivering an impressive 125 dB SPL. Sound is projected through a J-curve line array of ten 1.5-inch speakers paired with a best-in-class 12-inch subwoofer, providing clear, high-quality audio with a wide 170° horizontal coverage and powerful low-end performance.

Professional 5-Channel Digital Mixer with App Control

Take full command of your sound with the onboard 5-channel digital mixer. It offers versatile connectivity with three mono mic/line inputs (two with Hi-Z) and a stereo input, alongside professional features like 1-knob EQ and high-resolution SPX digital reverbs. For ultimate convenience, the STAGEPAS Controller app allows for comprehensive remote control of all parameters from your iOS or Android device.

Simple Setup and Superior Portability

Designed for performers on the move, the STAGEPAS 1K mkII is remarkably portable and easy to set up. The system's lightweight components, including the subwoofer, spacers, and array speaker, assemble quickly without the need for speaker stands or cables. A dedicated protective cover is included, making transport and storage simple and secure.

BY THE NUMBERS

Technical Specifications

Hardware & Setup

Body & Build

Finish & Colour

EssentialNo

Everything you receive

What's In The Box

Yamaha STAGEPAS 1K mkII Portable Column PA System with 1100W Amplifier, 12" Subwoofer, and 5-Channel Mixer
Owner's Manual
Local Warranty Card

Expert answers

Questions & Answers

6 questions answered by aDawliah experts·avg response 2 hours

The system features a 1100-watt Class-D amplifier and can produce a maximum sound pressure level (SPL) of 125 dB, making it suitable for a wide range of small to medium-sized venues.

Yes, channels 2 and 3 on the mixer are equipped with Hi-Z (high impedance) inputs, allowing you to connect instruments like electric-acoustic guitars or basses directly without needing a DI box.

No, the STAGEPAS 1K mkII is not battery powered and requires a connection to an AC power outlet to operate.

Yes, you can use the free Yamaha STAGEPAS Controller app on your iOS or Android smartphone or tablet to remotely control volume, EQ, reverb, and other mixer settings via Bluetooth.

The Yamaha STAGEPAS 1K mkII comes with the main subwoofer/mixer unit, the line array speaker, two spacer columns, a power cord, and a dedicated protective cover for the entire system.

The J-curve line array provides a very wide 170° horizontal coverage and a 30° vertical coverage, ensuring consistent sound quality across a broad listening area.
